RichAuto A132 Turning & Engraving Lathe DSP Controller
CNC lathe and turning motion controller with X/Z workflow, definable I/O and custom interface options.
Lathe DedicatedX/Z WorkflowCustomizable UI24V DCUSB + U DiskParam Backup
Documented model information verified.Replacing an existing controller? Send your current model label and machine configuration before ordering. We verify interface board, control signal, wiring and hardware revision wherever these affect compatibility.
IS THIS MODEL RIGHT FOR YOUR MACHINE?
A132 May Be a Good Fit If You Need:
Good fit for
- You build or run CNC lathes and turning machines
- You need X/Z lathe workflow with optional milling support
- You want definable I/O and a customizable interface
- You are replacing an A132 or similar turning controller
Consider another model if you need
- You need rotary/4-axis routing
- You need ATC or plasma controls
- You want a color display
SPECIFICATIONS
A132 Technical Specifications.
| Product model | A132 |
|---|---|
| Series | A1X |
| CPU | DSP |
| Internal memory | 512 MB |
| Display | Monochrome · 128×64 |
| Communication | U disk · USB cable |
| Controlled axes | 2 to 3 axes · X/Z lathe workflow with optional third axis |
| Control signal | Differential |
| Drive system | Stepper / Servo |
| I/O | 8 inputs / 8 outputs |
| Minimum input unit | 0.001 mm |
| Max. pulse frequency | 1 MHz |
| Power supply | 24V DC |
| Interpolation | Line, Arc, Curve |
| Breakpoint resume | Supported |
| Power-failure recovery | Supported |
| Soft / hard limit | Supported |
| Password protection | Supported |
| Rotary axis | Not supported |
| ATC support | Not supported |
| Multi-spindle / cylinders | Not supported |
| Plasma control | Not supported |
| Dispensing control | Not supported |
| Handwheel / MPG | Not supported |
| Network / PC control | Not supported |
KEY FUNCTIONS
What the A132 Brings to Your Machine.
- Dedicated CNC lathe system with standard X/Z two-axis control
- Supports lathe-milling machines and high-speed lathe processing
- Definable I/O interfaces for a wide development platform
- Parameter backup and restore plus password protection
- CE-tested anti-jamming performance
- Customizable operation interface for machine builders
COMPARE RELATED CONTROLLERS
Compare A132 with Related Controllers.
Related options help you avoid choosing a neighboring model by accident. Cards marked “different platform” are not direct replacements.
| Model | Main use | Axes | Display | I/O | Key capability | Relationship |
|---|---|---|---|---|---|---|
| A132 | CNC lathe and turning motion controller with X/Z workflow, definable I/O and custom interface options. | 2-3 | 128×64 | 8/8 | CNC lathe and turning motion controller with X/Z workflow, definable I/O and custom interface options. | This page |
A12, A132, A14, B57 and F1410 are special-purpose models. Related cards there show platform comparisons, not interchangeability.
REPLACEMENT & UPGRADE NOTES
Ordering A132 as a Replacement.
A132 is lathe-specific, not a general routing controller. Confirm the machine workflow, axis configuration and interface requirements with CINKR before ordering.
- Lathe control parameters and tooling workflow should be confirmed with machine details
DOWNLOADS
A132 Manuals, Wiring & Firmware.
Public manuals and general wiring references are free to download. Revision-sensitive firmware and diagrams are released after the controller details are verified.
FAQ
A132 — Questions to Check Before Ordering.
Is A132 just a general 3-axis controller?
No. A132 is the turning and engraving lathe variant with X/Z lathe workflow and optional milling support. Use it when the machine is a lathe or turning system.
Can the interface be customized?
Operation interface can be customized according to machine-builder requirements; definable I/O also supports secondary development.
Which file workflows does it support?
High-speed lathe processing with standard G-code from U disk; confirm the post-processor with the manual.
What should I send for an A132 quote?
Machine type, axis configuration, drive system and current controller so CINKR can confirm compatibility.
